Cylindrical tube quenching furnaceIt is a kind of equipment which uses gas as fuel and is specially used for heating metal before forging.。

1、Brief introduction of Cylindrical tube quenching furnace

Cylindrical tube quenching furnaceIt is an important heating equipment before metal forging. It uses natural gas as fuel to heat metal materials through high-temperature flame and smoke generated by combustion to meet the requirements of forging process.，usually used in aerospace, heat treatment, light industry, Household necessities, war industry and other fields，at the start of the operation,The high-temperature flame and flue gas generated when fuel (natural gas) burns in the furnace are used as heat sources to heat the medium flowing in the tube to reach the specified process temperature.。

Cylindrical tube quenching furnace

2、Structural characteristics of Cylindrical tube quenching furnace

The Cylindrical tube quenching furnace has the following structure

1. ventilation system

Ensure the gas flow in the furnace and maintain the stability of the atmosphere and temperature in the furnace.

2. combustor

The device that mixes natural gas with combustion-supporting air and ejects it is the core component of the heating furnace.

3. ventilation system

Ensure the gas flow in the furnace and maintain the stability of the atmosphere and temperature in the furnace.

4. Radiation chamber

The heat load of the main place for Cylindrical tube quenching furnace heat exchange accounts for about 70%-80% of the whole furnace. The furnace tube in the radiation room conducts heat through flame or high-temperature flue gas, which is mainly radiant heat, so it is called radiation tube.

5. Waste heat recovery system

Recover the waste heat in the exhaust gas of heating furnace to improve the energy utilization efficiency.

Cylindrical tube quenching furnace

3、Cylindrical tube quenching furnace advantage

Cylindrical tube quenching furnaces have the following advantages.

1. easy to operate

The operation interface of the Cylindrical tube quenching furnace is friendly and easy for operators to use. At the same time, the equipment also has the function of fault diagnosis and alarm, which can find and deal with abnormal situations in time.

2. Reduce operating costs

The efficient combustion and waste heat recovery system of the Cylindrical tube quenching furnace can significantly reduce energy consumption, thus reducing operating costs.

3. Multiple fuel options

Although the Cylindrical tube quenching furnace mainly uses natural gas as fuel, some equipment also supports other types of gas or liquid fuel, which has strong fuel adaptability.

4. Extend the service life of equipment

The Cylindrical tube quenching furnace adopts advanced combustion technology and materials, which has a long service life and low maintenance cost.

5. Wide application range

The Cylindrical tube quenching furnace is suitable for forging and heating of various metal materials, including steel, aluminum and copper. At the same time, it can also be used in metal heat treatment, tempering and other technological processes.

Cylindrical tube quenching furnace

4、Cylindrical tube quenching furnace function

Cylindrical tube quenching furnacemultifunctional, with functions such as Forging heating, quench, heat treatment, temper and hardening and tempering。

Cylindrical tube quenching furnace

5、Functional advantages of Cylindrical tube quenching furnace

Cylindrical tube quenching furnaces have the following advantages.

1. Efficient combustion

The Cylindrical tube quenching furnace adopts advanced combustion technology and control system, which can realize full combustion of natural gas and improve combustion efficiency. At the same time, some equipment is also equipped with waste heat recovery system, which can further recycle the waste heat in exhaust smoke and improve energy utilization efficiency.

2. Intelligent control

The Cylindrical tube quenching furnace is usually equipped with an intelligent control system, which can automatically adjust the parameters such as gas supply and air flow according to the heating demand, and realize accurate control of the temperature and atmosphere in the furnace.

3. Uniform heating

The Cylindrical tube quenching furnace adopts regenerative combustion system or advanced burner design, which can realize uniform distribution of temperature in the furnace, ensure uniform heating of metal materials and improve product quality.

4. Rapid temperature rise

The Cylindrical tube quenching furnace can heat the metal material to the required temperature in a short time, which improves the production efficiency.

5. Multiple fuel options

Although the Cylindrical tube quenching furnace mainly uses natural gas as fuel, some equipment also supports other types of gas or liquid fuel, which has strong fuel adaptability.

Cylindrical tube quenching furnace

6、Cylindrical tube quenching furnace video detail

One-combustion energy saving provides customers with on-site high-definition video, fully demonstrates the advantages of on-site productt operation, and helps customers to deeply understand the product production process and production site, and gain favorable comments and recognition from customers.。

Cylindrical tube quenching furnace

As you can see from the live video.，Shandong yiran energy-saving environment protection co., ltd It is a kind of heating equipment using natural gas as fuel, which is mainly used to heat metal materials to the required forging temperature in a short time.。

Cylindrical tube quenching furnaceit has the structure of recovery of waste heat, combustor, Radiation chamber, convection chamber and furnace chamber，the product looks beautiful.。
